Barrels & Tanks

2: Open Top, 1400gln. 5.25Ton, 49” H x 87” W on 32” adjustable stand. Large rectangular racking door with new gasket. 3” bottom racking valve. Canvas cover. $5000 each 2: Open Top, 1650gln. 6.5 Tons, 86” H x 86” W on 32” stainless steel adjustable stand. Round racking door. 2” racking valve and 3” bottom drain valve. Canvas covers. $7500 each 2: Open Top, 1450gln. 5.5 Tons, 86” H x 72” W on 32” stainless steel adjustable stand. Round racking door. 2” racking valve and 3” bottom drain valve. Canvas covers. $6000 each 1: 96” H x 72” W on 32” adjustable. Large rectangular racking door, round bottom door. 2” racking valve and 3” bottom drain valve. Top door middle back. $7000 6: R-Cool glycol Air Handlers: 84” L x 29” W. $1000 each. For more information or to schedule a visit, contact Scott @ [email protected]

Thank you for looking! Call or email for more details; [email protected] or 775-246-1180. Tank retails for $17,500 when built new. 1200 Gallon jacketed, brand new wine tank available from overstock; perfect for bottling line, fermentation, storage, etc. Won't last long; call for more information. 5' Dia 8' Sidewall Top 20" door with 2" TC vent Sidewall full drain rectangular manway (NO RACKING DOOR CURRENTLY INSTALLED - CAN BE ADDED + $980) Front oriented truncated top of tank Flat sloping bottom, to front 2" Racking arm 1" Sample temp hood 1/2" HC x 12" thermowell 3" TC Sump drain 2 zone, full circumference chilling jacket 4 stainless steel legs with height adjustable foot pads with anchoring bolt holes Price @ $12,000 Subject to prior sale; last unit in stock Thanks for looking!

All tanks are built and ready to ship. Built for a project that stalled and looking only to recover sunk costs on the builds. High end Silver State Stainless tanks at almost import prices. Email Daris for photos and design drawing details; or to talk about even deeper discounts for multi-tank purchases. [email protected] or 775-246-1180. 2 each - 500 Gallon Finished Spirits Holding Tanks, single wall, cone top and bottom, top manway, fork tubes and height adjustable legs. 304SS. 48" Diameter x 5' sidewall height. Atmospheric tank, API 650. Priced @ $7500 each 1 each - 1500 Gallon Hot Water Tank, insulated, non-jacketed; cone top, cone bottom. Side entry manway, large array of fittings in sidewall and top of tank; 5' 6" Inside Diameter, 5' 10" outside diameter; 8' straight sidewall. 304SS, #4 polished OD cladding. A beautiful tank for a hot water re-circulation or holding tank. 1 bar API 650. Price @ $15,500 each 1 each - 3000 Gallon Insulated Water tank, non-jacketed. Large array of fittings on top and sidewall of tank; similar to 1500 gallon hot water tank above. Overflow port and down tube and side entry manway at operator level. 7' Inside Diameter, 2" insulation package; …

1.Sanitary Stainless steel 304, thickness of material is 3mm; 2.Effective capacity: 1000L/1500L/2000L/3000L; 3. 0.75"Sample valve; 4.1.5" drain outlet assembly with tri-clamp connection; 5.1.5" wine outlet assembly with tri-clamp connection; 6. Fully welded cladding; 7.Top manway and the size for the manway is DN400mm; 8. Bimetal thermometer; 9.With cooling jacket, 1" coolant inlet and coolant outlet; 10.With side rectangle manway door, the size is 430mmx330mm; 11.Closed top tank; 12.Stackable legs. Please contact us for price and details! Shandong Chenma Machinery Co., Ltd Email: [email protected] Cel/Whats App:008613789827830 Website: http://www.sdchenma.com
